Audio Technica
BPHS2a-UT
Broadcast Stereo Headset with Dynamic Mic Unterminated
Created especially for news and sports broadcasting, this rugged stereo headset offers highly intelligible and commanding vocal reproduction, along with a comfortable fit and excellent sound isolation. Its low-profile, closed-back, on-ear design is based on the ATH-M60x professional monitor headphones and includes the same 45 mm large-aperture drivers, and premium, memory foam earpads and headband, giving users a high-fidelity headset that’s built to last. The headset’s hypercardioid dynamic microphone keeps the pickup focused on the broadcaster’s voice, even in loud environments, and is tailored to reproduce that voice with a rich, broadcast-ready sound. The microphone sits at the end of a rigid boom with a strong, flexible gooseneck section that allows the microphone to be easily adjusted and then stay in place. The boom is also designed to swivel forward and back so that the headset can be worn with the mic positioned on either the right or left side.
Specifications
| Microphone | |
|---|---|
| Element | Dynamic |
| Polar Pattern | Hypercardioid |
| Frequency Response | 50 - 14,000 Hz (@ 2 cm) |
| Open Circuit Sensitivity | –57 dB (5.6 mV) (0 dB = 1 V/Pa, 1 kHz) |
| Dimensions | Height: 18.0 mm (0.71”), Main unit maximum diameter: 23.4 mm (0.92”) |
| Output Connector | unterminated |
| Headphones | |
|---|---|
| Type | Closed-back Dynamic (Headphone) Hypercardioid Dynamic (Microphone) |
| Driver Diameter | 45 mm (Headphone) |
| Frequency Response | 15-28,000 Hz (Headphone) 50-14,000 Hz (Microphone) |
| Maximum Input Power | 1,600 mW at 1 kHz (Headphone) |
| Maximum Output | 1,600 mW |
| Sensitivity | 102 dB (Headphone) -57 dB (1.4 mV) re 1V at 1 Pa (Microphone) |
| Impedance | 38 ohms (Headphone) 550 ohms (Microphone) |
| Weight | 250 g (8.8 oz) |
| Cable | Detachable 3.0 m (9.8') long cable with 6-pin connector at headset end; 3-pin XLRM-type connector (microphone) and 3.5 mm (1/8") phone plug (headphone) outputs |
| Connector | TB6M jack |
| Magnet | Neodymium (Headphone) |
| Voice Coil | Copper-clad aluminum wire |
| Accessories Included | Pouch; 3 windscreens; cable clip; 6/3 mm (1/4") screw-on adapter |
