dB Technologies
IS-4TB
Passive, 4’’ Fullrange 8ohms, 40W RMS Power
IS4T is the tiniest amidst IS series cube speakers designed for permanent installation.
Equipped with a 4" component, this is a simple compact cabinet that fit-in everywhere, essentially designed for high quality background music.
IS cube speakers install in a few minutes thanks to the dedicated bracket included in the package.
Needless to say the keyword here is: ease of installation and unobtrusiveness. That's why each single system in IS series comes with a smooth design with few invisible pin points, Phoenix connectors, black or white version
Technical Data
| Speaker Type | Passive Fullrange Speaker |
Acoustical data
| RMS Power | 40 W |
| Peak Power | 160 W |
| Frequency Response [-6 dB] | 110 hz - 20,000 Hz |
| Impedance | 8 Ohm |
| Sensitivity 1W@m | 89 dB |
| Max SPL | 111 dB |
| LF | 1x 4", 1 " v.c. Fullrange woofer |
| Dispersion | 110x110° |
Input
| Connections | Phoenix |
Mechanics
| Housing | Plywood, water-painted coating |
| Rigging points | 2x M6 threaded nut |
| Accessories | bracket included |
| IP rating | IP 32 |
| Width | 130 mm (5.1 in) |
| Height | 130 mm (5.1 in) |
| Depth | 150 mm (5.9 in) |
| Weight | 2 kg (4.4 lbs) |
