Fifty Line is one of our most straightforward systems: easy transport options, smooth deployment with scalable options, outstanding final result.
Technical Data
Speaker Type
Active Subwoofer
Acoustical data
Frequency Response [-6dB]
38 Hz - Xover Frequency
Max SPL
135.4 dB
LF
1x 18"
LF Voice Coil
4"
Amplifier
Amp Technology
PSC1 with PFC
Amp Class
Class-D
Peak Power
3200 W
RMS Power
1600 W
Cooling
Passive Convection
Processor
Controller
DSP 32 bit
AD/DA Converter
24bit/96kHz
Input
Signal Input
1 x XLR female
Signal Out
1 x XLR male
USB connector
Type B - Data Service
Controls
1 rotary encoder (Preset)4 System LED (Limiter, Signal, Mute/Prot, Ready)3 RDNet LED (Link, Active, Remote Active)
Power Socket
1xPowerCon TRUE1 Mains 1xPowerCon TRUE1 Link
Mechanics
Housing
Plywood
Grille
Full metal grille
Rigging point
Flyable with accessories
Handles
2x side
Width
500 mm (19.7 in)
Height
750 mm (29.5 in)
Depth
600 mm (23.6 in)
Weight
42Kg (92.6 lbs.)
