Fifty Line is one of our most straightforward systems: easy transport options, smooth deployment with scalable options, outstanding final result.
Technical Data
| Speaker Type | 2-Way Active Full-range Speaker |
Acoustical data
| Frequency Response [-6dB] | 65 - 19.300 Hz |
| Max SPL | 137 dB |
| HF | 2x 1.4" exit |
| HF Voice Coil | 3" |
| Directivity (HxV) | 60 x +15°/- 35° |
| Crossover Frequency | 760 Hz |
| LF | 4x 10" |
| LF Voice Coil | 2" |
Amplifier
| Amp Technology | PSC1 with PFC |
| Amp Class | Class-D |
| Peak Power | 3200 W |
| RMS Power | 1600 W |
| Cooling | Passive Convection |
Processor
| Controller | DSP 32 bit |
| AD/DA Converter | 24bit/96kHz |
Input
| Signal Input | 1 x XLR female |
| Signal Out | 1 x XLR male |
| USB connector | Type B - Data Service |
| Controls | 1 rotary encoder (Preset)4 System LED (Limiter, Signal, Mute/Prot, Ready)3 RDNet LED (Link, Active, Remote Active) |
| Power socket | 1xPowerCon TRUE1 Mains 1xPowerCon TRUE1 Link |
Mechanics
| Housing | Plywood |
| Grille | Full metal grille |
| Rigging point | Flyable with accessories |
| Handles | 2x side |
| Width | 500 mm (19.7 in) |
| Height | 650 mm (25.6 in) |
| Depth | 600 mm (23.6 in) |
| Weight | 38.1Kg (84 lbs.) |
