Technical Data
| Speaker Type | Active Cardiod-Subwoofer |
Acoustical data
| Frequency Response [+/- 3dB] | 35 - 120 Hz |
| Max SPL | 140 dB |
| Directivity | Cardiod |
| LF | 18+15 " |
| Voice Coil LF | 4 " |
Amplifier
| Amp Technology | Digipro® G2 |
| Amp Class | Class D |
| Power Supply | 2.5 kW SMPS |
| LF Amp | 2500 W RMS |
| Cooling | Convection |
Processor
| Controller | DSP 56 bit |
| AD/DA Converter | 24bit/ 96 kHz |
| System Presets | X-Over,Delay |
| Phase | 0, 180 ° |
| Limiter | RMS, Peak, Thermal |
| Delay Option | 0-4.5 ms internal |
| Crossover Frequency LF-MF | 75-120Hz | steps of 5Hz |
| LF-Xover out slope | 24 dB/Octave |
Mechanics
| Housing | Multiplex plywood |
| Housing Design | Rectangular |
| Handles | 3x Per Side |
| Accessory | Dolly, Dust Cover, Rain Cover |
| Pole Mount | M20 |
| Rigging Points | integrated for SRK10 fly kit2xPick Points on top to fixDRK10/20 rigging frames |
| Width | 515 mm (20.6 in) |
| Height | 640 mm (25.6 in) |
| Depth | 1000 mm (40 in) |
| Weight | 65 kg (143.3 lbs) |
